Ultralytics YOLO26 ile Triton Inference Server

Triton Inference Server (eski adıyla TensorRT Inference Server), NVIDIA tarafından geliştirilen açık kaynaklı bir yazılım çözümüdür. NVIDIA GPU'ları için optimize edilmiş bir bulut çıkarım çözümü sunar. Triton, üretim ortamında ölçekli model sunumunu kolaylaştırır. Ultralytics YOLO26 ile Triton Inference Server'ı entegre ederek ölçeklenebilir, yüksek performanslı derin öğrenme çıkarım iş yükleri dağıtabilirsin. Bu kılavuz, entegrasyonu kurma ve test etme adımlarını açıklar.



İzle: NVIDIA Triton Inference Server'ı kullanmaya başlama.

Triton Inference Server nedir?#

Triton Inference Server, çeşitli yapay zekâ modellerini üretim ortamında dağıtmak için tasarlanmıştır. PyTorch, TensorFlow, ONNX, OpenVINO, TensorRT ve diğerleri dâhil olmak üzere çok çeşitli derin öğrenme ve makine öğrenimi çerçevelerini destekler. Başlıca kullanım alanları şunlardır:

  • Bir sunucu örneğinden birden fazla model sunma
  • Sunucuyu yeniden başlatmadan modelleri dinamik olarak yükleyip kaldırma
  • Sonuç elde etmek için birden fazla modelin birlikte kullanılmasını sağlayan topluluk çıkarımı
  • A/B testi ve aşamalı güncellemeler için model sürümleme

Triton Inference Server'ın Temel Avantajları#

Triton Inference Server'ı Ultralytics YOLO26 ile kullanmak çeşitli avantajlar sağlar:

  • Otomatik toplu işleme: İşleme başlamadan önce birden fazla AI isteğini bir araya getirerek verimi ve GPU kullanımını artırır.
  • Kubernetes entegrasyonu: Bulut tabanlı tasarımı, AI uygulamalarını yönetmek ve ölçeklendirmek için Kubernetes ile çalışır.
  • Donanıma özel optimizasyonlar: En yüksek performans için NVIDIA GPU'larından tam olarak yararlanır
  • Çerçeve esnekliği: PyTorch, TensorFlow, ONNX, OpenVINO ve TensorRT dahil olmak üzere birden fazla AI çerçevesini destekler.
  • Açık kaynaklı ve özelleştirilebilir: Çeşitli yapay zekâ uygulamalarında esneklik sağlayarak özel gereksinimlere uyacak şekilde değiştirilebilir

Ön koşullar#

Devam etmeden önce aşağıdaki ön koşulların karşılandığından emin ol:

  • Bilgisayarında Docker (>= 28.2.0, CDI GPU erişimi için NVIDIA Container Toolkit >= 1.18 ile) veya Podman yüklü olmalı
  • ultralytics yükle:
    pip install ultralytics
  • tritonclient yükle:
    pip install tritonclient[all]

Triton Inference Server'ı Kurma#

Ultralytics YOLO26'yı ONNX'e aktarmak, Triton model deposunu oluşturmak ve Triton Inference Server'ı başlatmak için bu kurulum bloğunun tamamını çalıştır:

Not

Kullanacağın kapsayıcı altyapısını seçmek için betikteki runtime anahtarını kullan:

  • Docker için runtime = "docker" değerini ayarla
  • Podman için runtime = "podman" değerini ayarla
import contextlib
import subprocess
import time
from pathlib import Path

from tritonclient.http import InferenceServerClient

from ultralytics import YOLO

runtime = "docker"  # set to "podman" to use Podman

# 1) Exporting YOLO26 to ONNX Format

# Load a model
model = YOLO("yolo26n.pt")  # load an official model

# Retrieve metadata during export. Metadata needs to be added to config.pbtxt. See next section.
metadata = []

def export_cb(exporter):
    metadata.append(exporter.metadata)

model.add_callback("on_export_end", export_cb)

# Export the model
onnx_file = model.export(format="onnx", dynamic=True)

# 2) Setting Up Triton Model Repository

# Define paths
model_name = "yolo"
triton_repo_path = Path("tmp") / "triton_repo"
triton_model_path = triton_repo_path / model_name

# Create directories
(triton_model_path / "1").mkdir(parents=True, exist_ok=True)

# Move ONNX model to Triton Model path
Path(onnx_file).rename(triton_model_path / "1" / "model.onnx")

# Create config file
(triton_model_path / "config.pbtxt").touch()

data = """
# Add metadata
parameters {
  key: "metadata"
  value {
    string_value: "%s"
  }
}

# Enable TensorRT acceleration (requires a GPU and TensorRT-enabled Triton; remove this block for CPU-only serving)
# The first run will be slow due to TensorRT engine conversion
optimization {
  execution_accelerators {
    gpu_execution_accelerator {
      name: "tensorrt"
      parameters {
        key: "precision_mode"
        value: "FP16"
      }
      parameters {
        key: "max_workspace_size_bytes"
        value: "3221225472"
      }
      parameters {
        key: "trt_engine_cache_enable"
        value: "1"
      }
      parameters {
        key: "trt_engine_cache_path"
        value: "/models/yolo/1"
      }
    }
  }
}
""" % metadata[0]  # noqa

with open(triton_model_path / "config.pbtxt", "w") as f:
    f.write(data)

# 3) Running Triton Inference Server

# Define image https://catalog.ngc.nvidia.com/orgs/nvidia/containers/tritonserver
tag = "nvcr.io/nvidia/tritonserver:26.02-py3"  # 16.17 GB (Compressed Size)

subprocess.call(f"{runtime} pull {tag}", shell=True)

# CDI GPU request works identically on Docker and Podman
gpu_flags = "--device nvidia.com/gpu=all"

container_name = "triton_server"

# Note: The :z flag on the volume mount is necessary for systems with SELinux (like Fedora/RHEL)
subprocess.call(
    f"{runtime} run -d --rm --name {container_name} {gpu_flags} -v {triton_repo_path.absolute()}:/models:z -p 8000:8000 {tag} tritonserver --model-repository=/models",
    shell=True,
)

# Wait for the Triton server to start
triton_client = InferenceServerClient(url="127.0.0.1:8000", verbose=False, ssl=False)

# Wait until model is ready
for _ in range(10):
    with contextlib.suppress(Exception):
        assert triton_client.is_model_ready(model_name)
        break
    time.sleep(1)

Çıkarımı Çalıştırma#

Triton Server modelini kullanarak çıkarımı çalıştır:

from ultralytics import YOLO

# Triton Server modelini yükle
model = YOLO("http://127.0.0.1:8000/yolo", task="detect")

# Sunucuda çıkarımı çalıştır
results = model("path/to/image.jpg")

Konteyneri temizle:

import subprocess

runtime = "docker"  # set to "podman" to use Podman
container_name = "triton_server"  # Kill the named container
subprocess.call(f"{runtime} kill {container_name}", shell=True)

TensorRT Optimizasyonu (İsteğe Bağlı)#

Daha yüksek performans için Triton Inference Server ile TensorRT kullanabilirsin. TensorRT, NVIDIA GPU'ları için özel olarak geliştirilmiş yüksek performanslı bir derin öğrenme iyileştiricisidir ve çıkarım hızını önemli ölçüde artırabilir.

TensorRT'yi Triton ile kullanmanın başlıca avantajları şunlardır:

  • NVIDIA'ya göre yalnızca CPU kullanan platformlardan 36 kata kadar daha hızlı çıkarım.
  • GPU kullanımını en üst düzeye çıkarmak için donanıma özel optimizasyonlar
  • Doğruluğu korurken azaltılmış hassasiyet biçimlerini (INT8, FP16) destekleme
  • Hesaplama yükünü azaltmak için katmanları birleştirme

Yukarıdaki config.pbtxt, ONNX modeli için Triton'ın TensorRT hızlandırıcısını zaten etkinleştirir. Bunun yerine TensorRT'yi doğrudan Ultralytics ile çalıştırmak için Ultralytics YOLO26 modelini TensorRT biçimine aktar:

from ultralytics import YOLO

# YOLO26 modelini yükle
model = YOLO("yolo26n.pt")

# Modeli TensorRT biçimine aktar
model.export(format="engine")  # 'yolo26n.engine' oluşturur

TensorRT optimizasyonu hakkında daha fazla bilgi için TensorRT entegrasyon kılavuzuna göz at.

Artık ölçeklenebilir ve yüksek performanslı çıkarım için Ultralytics YOLO26 modellerini Triton Inference Server üzerinde dağıtıp çalıştırabilirsin. Yönetilen barındırmayı tercih ediyorsan Ultralytics Platform özel dağıtım uç noktaları sunar.

Sık Sorulan Sorular#

  • Ultralytics YOLO26 modelini NVIDIA Triton Inference Server ile kurmak birkaç temel adımdan oluşur:

    1. YOLO26'yı ONNX biçiminde dışa aktar:

      from ultralytics import YOLO

      # Bir model yükle
      model = YOLO("yolo26n.pt")  # Resmî bir modeli yükle

      # Modeli ONNX biçimine aktar
      onnx_file = model.export(format="onnx", dynamic=True)
    2. Triton Model Deposunu kur:

      from pathlib import Path

      # Yolları tanımla
      model_name = "yolo"
      triton_repo_path = Path("tmp") / "triton_repo"
      triton_model_path = triton_repo_path / model_name

      # Dizinleri oluştur
      (triton_model_path / "1").mkdir(parents=True, exist_ok=True)
      Path(onnx_file).rename(triton_model_path / "1" / "model.onnx")
      (triton_model_path / "config.pbtxt").touch()
    3. Triton Server'ı çalıştır:

      import contextlib
      import subprocess
      import time

      from tritonclient.http import InferenceServerClient

      # Define image https://catalog.ngc.nvidia.com/orgs/nvidia/containers/tritonserver
      tag = "nvcr.io/nvidia/tritonserver:26.02-py3"

      runtime = "docker"  # set to "podman" to use Podman
      subprocess.call(f"{runtime} pull {tag}", shell=True)

      # CDI GPU request works identically on Docker and Podman
      gpu_flags = "--device nvidia.com/gpu=all"

      container_name = "triton_server"
      subprocess.call(
          f"{runtime} run -d --rm --name {container_name} {gpu_flags} -v {triton_repo_path.absolute()}:/models:z -p 8000:8000 {tag} tritonserver --model-repository=/models",
          shell=True,
      )

      triton_client = InferenceServerClient(url="127.0.0.1:8000", verbose=False, ssl=False)

      for _ in range(10):
          with contextlib.suppress(Exception):
              assert triton_client.is_model_ready(model_name)
              break
          time.sleep(1)

    Bu kurulum, yüksek performanslı AI modeli çıkarımı için Ultralytics YOLO26 modellerini Triton Inference Server'da verimli ve büyük ölçekte dağıtmana yardımcı olabilir.

  • Ultralytics YOLO26'yı NVIDIA Triton Inference Server ile entegre etmek çeşitli avantajlar sağlar:

    • Ölçeklenebilir yapay zekâ çıkarımı: Triton, tek bir sunucu örneğinden birden fazla modelin sunulmasına olanak tanır. Modellerin dinamik olarak yüklenip kaldırılmasını desteklediğinden farklı yapay zekâ iş yükleri için yüksek ölçeklenebilirlik sağlar.
    • Yüksek performans: NVIDIA GPU'ları için optimize edilen Triton Inference Server, nesne algılama gibi gerçek zamanlı uygulamalar için ideal, yüksek hızlı çıkarım işlemleri sağlar.
    • Topluluk ve model sürümleme: Triton'ın topluluk modu, sonuçları iyileştirmek için birden fazla modeli birleştirmeyi sağlar; model sürümleme özelliği ise A/B testlerini ve aşamalı güncellemeleri destekler.
    • Otomatik Toplu İşleme: Triton birden fazla çıkarım isteğini otomatik olarak bir araya getirerek verimi önemli ölçüde artırır.
    • Basitleştirilmiş Dağıtım: Ultralytics bir Triton uç noktasını yerel bir model gibi yükler; böylece çıkarım kodunu yeniden yazmadan Triton'ı kullanabilirsin.
  • Ultralytics YOLO26 modelini NVIDIA Triton Inference Server'da dağıtmadan önce ONNX (Açık Sinir Ağı Değişimi) biçimini kullanmak çeşitli önemli avantajlar sunar:

    • Birlikte çalışabilirlik: ONNX biçimi, farklı derin öğrenme çerçeveleri (PyTorch, TensorFlow gibi) arasında aktarımı destekleyerek daha geniş uyumluluk sağlar.
    • Optimizasyon: Triton dâhil olmak üzere birçok dağıtım ortamı ONNX için optimizasyon yaparak daha hızlı çıkarım ve daha iyi performans sağlar.
    • Kolay dağıtım: ONNX, çeşitli işletim sistemlerinde ve donanım yapılandırmalarında dağıtım sürecini basitleştirerek çerçeveler ve platformlar genelinde yaygın biçimde desteklenir.
    • Çerçeveden bağımsızlık: ONNX'e dönüştürüldükten sonra modelin orijinal çerçevesine bağlı kalmaz ve daha taşınabilir hâle gelir.
    • Standartlaştırma: ONNX, farklı AI çerçeveleri arasındaki uyumluluk sorunlarının aşılmasına yardımcı olan standartlaştırılmış bir gösterim sunar.

    Modelini dışa aktarmak için şunu kullan:

    from ultralytics import YOLO

    model = YOLO("yolo26n.pt")
    onnx_file = model.export(format="onnx", dynamic=True)

    İşlemi tamamlamak için ONNX entegrasyon kılavuzundaki adımları izleyebilirsin.

  • Evet, NVIDIA Triton Inference Server'da Ultralytics YOLO26 modeliyle çıkarım yapabilirsin. Modelin Triton Model Repository'de kurulup sunucu çalışmaya başladıktan sonra modelini aşağıdaki gibi yükleyip çıkarım yapabilirsin:

    from ultralytics import YOLO

    # Triton Server modelini yükle
    model = YOLO("http://127.0.0.1:8000/yolo", task="detect")

    # Sunucuda çıkarımı çalıştır
    results = model("path/to/image.jpg")

    Bu yaklaşım, tanıdık Ultralytics YOLO arayüzünü kullanırken Triton'un optimizasyonlarından yararlanmanı sağlar.

  • Ultralytics YOLO26, dağıtım açısından TensorFlow ve PyTorch modellerine kıyasla çeşitli benzersiz avantajlar sunar:

    • Gerçek Zamanlı Performans: Gerçek zamanlı nesne tespiti görevleri için optimize edilen Ultralytics YOLO26, yüksek doğruluk ve hız sunar; bu nedenle canlı video analitiği gerektiren uygulamalar için oldukça uygundur.
    • Kullanım Kolaylığı: Ultralytics YOLO26, Triton Inference Server ile çalışır ve çeşitli dışa aktarma biçimlerini (ONNX, TensorRT) destekleyerek farklı dağıtım senaryolarına uyum sağlar.
    • Gelişmiş Özellikler: Triton üzerinden sunum; ölçeklenebilir ve güvenilir AI dağıtımları için kritik olan dinamik model yükleme, model sürümleme ve toplu çıkarım özelliklerini ekler.
    • Basitleştirilmiş API: Ultralytics API, farklı dağıtım hedeflerinde tutarlı bir arayüz sunarak öğrenme süresini ve geliştirme süresini kısaltır.
    • Uç Cihazlar için Optimizasyon: Ultralytics YOLO26 modelleri uç cihazlara dağıtım düşünülerek tasarlanmıştır ve kaynakları kısıtlı cihazlarda bile güçlü performans sunar.

    Daha fazla bilgi için dağıtım seçeneklerini model dışa aktarma kılavuzunda karşılaştır.
